Features
- 90° x 50° coverage
- Dual-angle pole socket for applications requiring tripod mounting
- Heavy Duty 16 gauge protective screen backed steel grille
- Tough DuraFlex™ enclosure finish
- SonicGuard™ protects the highfrequency driver from excess power without interrupting the performance.
Applications
- Reinforcement of music and speech in entertainment, live or pre-recorded applications
- High-performance satellite speaker for use with subwoofers
Specifications
| Frequency Range (-10dB) | 55 Hz – 19 kHz |
| Frequency Response (±3 dB) | 66 Hz – 16 kHz |
| Coverage Pattern | 90° x 50° nominal |
| System Sensitivity | 98 dB SPL (1w@1m) |
| Power Rating, Pink Noise | 300 W / 600 W / 1200 W(Continuous/Program/Peak) |
| Maximum SPL (1m) | 122 dB SPL cont. (129 dB SPL peak) |
| Nominal Impedance | 8 ohms |
| Dimensions (H x W x D) | 650 mm x 429 mm x 457 mm (25.6" x 16.9" x 18") |
| Net Weight | 21 kg (46 lbs.) |
| Inputs | Parallel Neutrik® Speakon® NL-2 / ¼" phone combo jacks |
| Enclosure | Duraflex coated plywood |
